Perkins Engine Torque Chart(For All Models/Series)

Understanding the torque ratings by model is key for optimal performance, troubleshooting, and equipment matching.

In this post, we’ve compiled a detailed Perkins Engine Torque Chart that includes various engine families – from the compact 400 Series to the powerful 2800 Series. Whether you’re a mechanic, fleet manager, or enthusiast, this chart will help you get quick insights into your Perkins engine torque output.

Perkins Engine Torque Chart

Engine Model	Series	Rated Power (kW/HP)	Peak Torque (Nm)	Torque RPM
402J-05	400	10.2 kW / 13.7 HP	44 Nm	2400 RPM
403J-07	400	15.3 kW / 20.5 HP	66 Nm	2200 RPM
403J-11	400	18.4 kW / 24.7 HP	86 Nm	2200 RPM
403J-17T	400	30.1 kW / 40 HP	120 Nm	1800 RPM
404J-22	400	36.0 kW / 48 HP	190 Nm	1800 RPM
404J-E22T	400	48 kW / 64 HP	208 Nm	1600 RPM
403F-15T	400	24.6 kW / 33 HP	105 Nm	1800 RPM
404F-E22TA	400	55 kW / 74 HP	240 Nm	1800 RPM
804D-33	800	47.1 kW / 63 HP	221 Nm	1600 RPM
804D-33T	800	61.5 kW / 82 HP	276 Nm	1400 RPM
854E-E34T	850	86 kW / 115 HP	420 Nm	1400 RPM
854E-E34TA	850	100 kW / 134 HP	490 Nm	1400 RPM
1103D-33	1100	42.2 kW / 56.6 HP	265 Nm	1400 RPM
1103D-33TA	1100	74.5 kW / 100 HP	393 Nm	1400 RPM
1104D-44	1100	56.0 kW / 75 HP	308 Nm	1400 RPM
1104F-44T	1100	82 kW / 110 HP	450 Nm	1400 RPM
1106D-E66TA (Tier 3)	1100	151 kW / 202 HP	800 Nm	1400 RPM
1106J-E70TA	1100	129 kW / 173 HP	750 Nm	1400 RPM
1204E-E44T	1200	81 kW / 109 HP	500 Nm	1400 RPM
1204E-E44TA	1200	97 kW / 130 HP	550 Nm	1400 RPM
1206J-E70TA	1200	168 kW / 225 HP	980 Nm	1400 RPM
1206F-E70TTA	1200	186 kW / 250 HP	1050 Nm	1400 RPM
1506A-E88TAG3	1500	330 kW / 442 HP	1890 Nm	1500 RPM
1506D-E88TAG5	1500	403 kW / 540 HP	2310 Nm	1500 RPM
2006TW	2000	217 kW / 291 HP	1130 Nm	1500 RPM
2206A-E13TAG2	2200	407 kW / 546 HP	2370 Nm	1500 RPM
2206A-E13TAG3	2200	450 kW / 603 HP	2610 Nm	1500 RPM
2506C-E15TAG1	2500	435 kW / 583 HP	2600 Nm	1500 RPM
2506C-E15TAG3	2500	500 kW / 670 HP	2900 Nm	1500 RPM
2806J-E18TAG1	2800	635 kW / 850 HP	3620 Nm	1500 RPM
2806A-E18TAG2	2800	670 kW / 900 HP	3800 Nm	1500 RPM
4006-23TAG1A	4000	705 kW / 945 HP	4000 Nm	1500 RPM
4006-23TAG2A	4000	800 kW / 1072 HP	4500 Nm	1500 RPM
4008TAG1A	4000	900 kW / 1207 HP	5100 Nm	1500 RPM
4008TAG2A	4000	1000 kW / 1340 HP	5600 Nm	1500 RPM
4012-46TAG2A	4000	1375 kW / 1844 HP	7700 Nm	1500 RPM
4016-61TRG3	4000	2000 kW / 2682 HP	11300 Nm	1500 RPM

Note: Torque and power values may vary slightly depending on specific configurations (e.g., turbocharged, aftercooled) and application.

Related Perkins 4 Cylinder Diesel Engine Oil Capacity(For All Models)

Understanding the Chart

Here are a few key insights from the torque chart:

• Compact Models (400 Series): These engines offer torque in the 26–240 Nm range, ideal for light-duty applications like pumps, compressors, and small gensets.
• Midrange Workhorses (1100 & 850 Series): These engines are versatile for industrial machinery, agricultural tractors, and construction equipment, with torque ranging from 300–750 Nm.
• Heavy-Duty Engines (1200, 1500, 2200, 2500, 2800 Series): Designed for power-intensive applications such as large gensets and mining equipment, these models deliver massive torque outputs up to 3500 Nm.

Related CC to Hp Calculator

Why Torque Matters in Perkins Engines

Torque is essential for:

• Tractor & Loader Applications: More torque allows for smoother operation under load, especially in rough terrain or while hauling.
• Generators (Gensets): Torque at low RPM ensures fuel efficiency and stable electricity generation.
• Industrial Equipment: Forklifts, backhoes, and cranes rely on high torque to operate heavy components smoothly.
• Marine Engines: Continuous torque delivery ensures propulsion systems remain stable under changing sea conditions.

Related Oil Drain Plug Torque Chart(Vehicles A to Z)

How to Use the Torque Chart

This torque chart can guide you in:

• Selecting the right engine: Match torque output with the workload requirement.
• Troubleshooting performance issues: Low torque might indicate engine wear, fuel system problems, or incorrect tuning.
• Planning engine upgrades: If you’re looking to upsize a power unit, torque should be a key decision factor.

Related Truck Engine Oil Capacity Chart(For All Models)

What Is Engine Torque?

Torque is the rotational force an engine generates, measured in Newton meters (Nm) or pound-feet (lb-ft). More torque typically means better towing power, pulling strength, and load-bearing capacity. In diesel engines like Perkins, high torque at low RPMs is particularly valuable in off-road and heavy-duty applications.

FAQs

How many horsepower is a 4 cylinder Perkins diesel?

The horsepower of a 4-cylinder Perkins diesel engine varies by model and series. For example, the Perkins 404D-22 produces around 48.7 HP, while the 1104D-44T delivers up to 100 HP. Modern 4-cylinder Perkins engines can range from 30 HP to over 130 HP, depending on turbocharging, emissions tier, and application.

What is the specs of the Perkins 6.247 diesel engine?

The Perkins 6.247 is a 6-cylinder, naturally aspirated diesel engine used in older tractors and industrial machines. It typically produces around 90–98 HP with a displacement of 6.1 liters (372 cu in). Peak torque is around 300–330 Nm at 1400–1500 RPM. It was widely used in agricultural and construction equipment in the 1970s and 1980s.

What is the correct torque for cylinder head bolts?

Cylinder head bolt torque for Perkins engines varies by model. For example:

• Perkins 400 Series: ~80–100 Nm
• 1100 Series: ~150–180 Nm
• 6-cylinder models: ~200–220 Nm
• Always refer to the official Perkins service manual for your specific engine model, as bolt stretch and sequence are also critical.

What is the spec of Perkins 1104C-44 engine?

The Perkins 1104C-44 is a naturally aspirated 4-cylinder diesel engine with:

• Displacement: 4.4 liters
• Power: 74.5 kW / 100 HP (approx.)
• Torque: Around 380–400 Nm @ 1400 RPM
• Applications: Used in agricultural tractors, loaders, generators, and industrial equipment
• It meets Tier 2 or Stage II emissions, depending on configuration.

How to calculate diesel engine horsepower?

To calculate diesel engine horsepower (HP), you can use the torque formula:

HP = (Torque × RPM) ÷ 5252 (for lb-ft)

or

HP = (Torque × RPM) ÷ 7127 (for Nm)

For example, if a diesel engine produces 500 Nm at 1500 RPM:

HP = (500 × 1500) ÷ 7127 ≈ 105 HP

How to identify a Perkins engine?

You can identify a Perkins engine by checking the engine serial number (ESN), typically found on a metal plate riveted to the engine block or stamped on the casting. The ESN includes:

• Engine family
• Build list
• Serial number
• You can use this number on Perkins’ official engine lookup tool or parts catalog to find full specifications, model, and parts compatibility.

Final Thoughts

Perkins engines have a long-standing reputation for durability, reliability, and efficiency. Knowing the torque output of your engine model helps you make smarter decisions about usage, maintenance, and upgrades. Whether you’re operating a compact generator or a large excavator, torque is the backbone of engine performance – and now, you have the figures at your fingertips.
