Refrigerant capacity varies by model, year, engine size and body style.
This guide provides a comprehensive Ford refrigerant capacity chart in table format, covering passenger cars, SUVs, trucks, and vans.
Ford Refrigerant Capacity Charts
| Ford Model | Year Range | Refrigerant Type | Capacity (grams) | Notes |
|---|---|---|---|---|
| Ford Fiesta | 1999–2002 | R134a | 725–755 | Front A/C |
| Ford Fiesta | 2003–2007 | R134a | 500–600 | Engine dependent |
| Ford Fiesta VI | 2008–2013 | R134a | 390–475 | Small system |
| Ford Fiesta VII | 2013–2017 | R134a | 650–675 | Larger condenser |
| Ford Fiesta VIII | 2017–2023 | R1234yf | 500–650 | New refrigerant |
| Ford Focus I | 1999–2004 | R134a | 700–750 | |
| Ford Focus II | 2005–2010 | R134a | 525–600 | |
| Ford Focus III | 2011–2015 | R134a | 460–530 | |
| Ford Focus IV | 2016–2023 | R1234yf | 530–625 | |
| Ford Mondeo III | 2001–2007 | R134a | 700–900 | |
| Ford Mondeo IV | 2007–2014 | R134a | 600–650 | |
| Ford Mondeo V | 2015–2022 | R1234yf | 560–580 | |
| Ford Fusion (US) | 2006–2012 | R134a | 620–700 | |
| Ford Fusion | 2013–2020 | R1234yf | 550–600 | |
| Ford C-Max | 2010–2018 | R134a | 460–530 | |
| Ford B-Max | 2012–2017 | R134a | 550–650 | |
| Ford EcoSport | 2013–2022 | R134a | 600–650 | |
| Ford Kuga I | 2008–2012 | R134a | 600–650 | |
| Ford Kuga II | 2013–2019 | R1234yf | 480–600 | |
| Ford Escape | 2008–2012 | R134a | 650–700 | |
| Ford Escape | 2013–2023 | R1234yf | 550–600 | |
| Ford Edge | 2007–2014 | R134a | 700–750 | |
| Ford Edge | 2015–2023 | R1234yf | 600–650 | |
| Ford Explorer | 2006–2010 | R134a | 750–850 | |
| Ford Explorer | 2011–2019 | R134a | 700–900 | Rear A/C option |
| Ford Explorer | 2020–2023 | R1234yf | 650–750 | |
| Ford Ranger | 1998–2006 | R134a | 700–800 | |
| Ford Ranger | 2011–2023 | R134a | 600–650 | |
| Ford Maverick | 2022–2024 | R1234yf | 500–550 | |
| Ford Mustang | 2005–2014 | R134a | 550–600 | |
| Ford Mustang | 2015–2023 | R1234yf | 550–620 | |
| Ford F-150 | 2004–2014 | R134a | 750–850 | |
| Ford F-150 | 2015–2023 | R1234yf | 650–750 | |
| Ford Transit Connect | 2010–2013 | R134a | 525–600 | |
| Ford Transit Connect | 2014–2023 | R134a | 650–800 | |
| Ford Transit | 2006–2014 | R134a | 900–1200 | Cargo van |
| Ford Transit | 2015–2023 | R134a | 950–1430 | Rear A/C |
| Ford Galaxy | 1995–2000 | R134a | 950–1400 | |
| Ford Galaxy | 2001–2015 | R134a | 800–900 | |
| Ford S-Max | 2006–2014 | R134a | 650–700 | |
| Ford S-Max | 2015–2022 | R1234yf | 550–600 |
Related Ford Engine Sizes Chart(For All Engine Types)
Ford Refrigerant Types
R134a
R134a was the standard refrigerant used in Ford vehicles for many years. It is still found in many older models and some commercial vehicles. Systems designed for R134a must never be charged with R1234yf.
R1234yf
R1234yf is a newer, low global-warming-potential refrigerant now used in most modern Ford vehicles. It requires specialized service equipment and compatible compressor oil.
Related Engine Ford Vin Decoder(For All Models)
Why Refrigerant Capacity Matters
Charging the A/C system with the correct amount of refrigerant is critical because:
- Too little refrigerant causes weak cooling and compressor overheating
- Too much refrigerant increases system pressure and can damage seals
- An incorrect charge weight reduces fuel efficiency
- Improper charging shortens compressor lifespan
Ford engineers design each A/C system to operate at a specific refrigerant weight, not a pressure reading alone.
What Causes Capacity Differences
Refrigerant capacity can vary even within the same model due to:
- Engine size and layout
- Condenser size
- Presence of rear air conditioning
- Climate package or heavy-duty cooling
- Model year updates
This is why capacities are often shown as a range rather than a single number.
Related Ford Engine Oil Capacity Chart(For ALL Models)
How to Confirm the Exact Capacity for Your Ford
Before servicing the A/C system, always verify:
- The under-hood A/C label
- The owner’s manual
- Factory service data
- Dealer or professional service equipment
The chart above should be used as a general reference, not a replacement for vehicle-specific labeling.
Best Practices When Recharging Ford A/C Systems
- Always recover old refrigerant before recharging
- Never mix refrigerant types
- Use the correct PAG oil specified for the refrigerant
- Check for leaks before adding refrigerant
- Measure refrigerant by weight, not pressure alone
Related Ford Engine Swap Chart(For All Engines Types)
FAQs
How much refrigerant does a Ford F150 need?
The amount of refrigerant depends on the model year and engine. Generally, Ford F‑150 trucks require between 650 and 850 grams (23–30 ounces) of refrigerant. Always refer to the under-hood A/C label for the exact specification.
How much R-134a refrigerant do I need?
For Ford vehicles equipped with R‑134a, the required amount varies by model, engine, and whether the system has rear A/C. Typical capacities range from 500 to 850 grams (17.6–30 ounces). Charging by weight is essential for optimal cooling and system safety.
How much R-134a does a 2003 Ford F150 hold?
The 2003 Ford F‑150, depending on engine size and system configuration, generally holds approximately 750–800 grams (26–28 ounces) of R‑134a refrigerant. Confirm the exact amount on the under-hood label before servicing.
How much freon does a 2007 Ford F150 5.4 L take?
A 2007 Ford F‑150 with the 5.4 L engine typically requires around 750–800 grams (26–28 ounces) of R‑134a refrigerant for proper A/C operation. System pressure readings should not be used as a substitute for charging by weight.
Can you recharge R-1234YF yourself?
R‑1234yf systems can technically be recharged by DIYers, but they require specialized equipment and safety precautions due to the refrigerant’s flammability. Professional service is strongly recommended to prevent accidents and ensure the system is correctly charged.
How much freon does a 2006 Ford F150 take?
A 2006 Ford F‑150 generally requires approximately 750–850 grams (26–30 ounces) of R‑134a refrigerant, depending on the engine size and whether rear A/C is installed. Always use the vehicle-specific A/C label for accuracy.
How much to recharge AC in Ford F150?
Recharging the A/C system in a Ford F‑150 requires measuring refrigerant by weight, typically 650–850 grams (23–30 ounces). Use the manufacturer-specified refrigerant type (R‑134a for older models, R‑1234yf for newer models) and never overfill the system.
Final words
Ford refrigerant capacity charts are a crucial reference for proper air conditioning (A/C) servicing. While this guide covers a wide range of Ford cars, trucks, SUVs, and vans, always confirm the exact specification for your vehicle before recharging. Using the correct refrigerant type and capacity ensures reliable cooling, protects the compressor, and extends the life of the air conditioning system.
