An engine bearing clearance chart helps mechanics and engine builders understand typical clearance ranges for main bearings, connecting rod bearings, and other engine components. Incorrect clearance can cause low oil pressure, knocking noises, overheating, and serious engine damage.
Engine Bearing Clearance Chart
| Engine Bearing Type / Condition | Typical Clearance / Symptoms | Common Causes | Recommended Fix |
|---|---|---|---|
| Main crankshaft bearings | 0.0010–0.0030 in (0.025–0.076 mm), general reference | Bearing wear, worn journals, incorrect sizing | Measure journals and bearing bores; verify factory specifications |
| Connecting rod bearings | 0.0010–0.0030 in (0.025–0.076 mm), general reference | Oil starvation, bearing wear, excessive clearance | Inspect rod bearings and crankshaft journals |
| Camshaft bearings | Engine-specific; varies by design | Worn bearings, misalignment, inadequate lubrication | Measure clearance according to the service manual |
| Thrust bearings | Manufacturer-specified crankshaft endplay | Worn thrust surfaces, incorrect installation | Measure axial movement with a dial indicator |
| Small-block gasoline engine bearings | 0.0015–0.0025 in (0.038–0.064 mm), illustrative reference | Incorrect bearing grade, worn crankshaft | Verify engine-specific bearing clearances |
| Performance engine bearings | Application-specific; some designs use wider clearances | High loads, operating temperature, incorrect setup | Follow engine builder and bearing manufacturer specifications |
| Diesel engine bearings | Engine-specific | Heavy loading, oil starvation, wear | Check factory specifications and journal dimensions |
| Motorcycle engine bearings | Engine-specific | Incorrect assembly, wear, lubrication problems | Follow the manufacturer’s measurement procedure |
| Small-engine crankshaft bearings | Engine-specific | Worn components, inadequate lubrication | Check the engine model’s service manual |
| Excessive bearing clearance | Low oil pressure, knocking, abnormal wear | Worn journals, incorrect bearing size | Measure components and install correctly sized bearings |
| Insufficient bearing clearance | Overheating, tight rotation, possible seizure | Incorrect bearing selection, machining errors | Recheck dimensions and correct the clearance |
| Uneven bearing clearance | Localized wear, noise, premature failure | Journal taper, out-of-round, housing misalignment | Inspect and measure all relevant surfaces |
| Bearing oil starvation | Scoring, discoloration, knocking | Blocked oil passages, low oil level, oil pump problems | Correct the lubrication problem and inspect damaged parts |
Important: The numerical ranges above are general references for selected applications, not universal factory specifications. Always consult the manufacturer’s service manual for the exact engine, model year, and bearing arrangement.
Related Engine Bearing Failure Chart(All Failure Types + Fixes)
What Is Engine Bearing Clearance?
Engine bearing clearance is the space between the installed bearing surface and the crankshaft journal or other supported shaft. In an engine, this space allows oil to flow through the bearing and maintain a lubricating film between moving surfaces.
For example, main bearings support the crankshaft in the engine block, while connecting rod bearings support the crankshaft where the connecting rods attach. Both require suitable clearance to operate correctly.
The clearance must be large enough to provide adequate lubrication but not so large that excessive oil escapes from the bearing surfaces. Manufacturers establish specifications based on engine design, bearing dimensions, lubrication requirements, and operating conditions.
Main Bearing vs. Connecting Rod Bearing Clearance
Main bearings and connecting rod bearings perform different jobs, even though their clearance ranges can overlap.
Main bearings support the crankshaft and help maintain its position as it rotates. Connecting rod bearings transfer combustion loads from the pistons and connecting rods to the crankshaft.
Both bearing types must be inspected during an engine rebuild. Worn bearings, damaged crankshaft journals, or incorrectly selected bearing shells can cause clearance to fall outside the approved range.
Never assume that the main bearing clearance specification is identical to the connecting rod bearing specification. Check both independently against the correct service information.
Related Engine Connecting Rod Bearing Size Chart(For All Vehicle Brands)
What Happens When Bearing Clearance Is Too Tight?
Insufficient bearing clearance can restrict the oil film between the bearing and crankshaft journal. This can increase friction and operating temperature, particularly when the engine is under load.
Possible consequences include:
- Excessive friction and heat.
- Bearing surface damage or wiping.
- Restricted oil flow through the bearing.
- Crankshaft rotation that feels unusually tight during assembly.
- Bearing seizure or severe engine damage in extreme cases.
Tight clearance may result from incorrect bearing selection, machining errors, an incorrectly sized crankshaft journal, or contamination trapped behind a bearing shell.
Before assembly, verify the dimensions of the crankshaft journals, bearing housings, and selected bearing shells.
What Happens When Bearing Clearance Is Too Loose?
Excessive clearance allows more oil to escape through the bearing than the design intends. This can contribute to reduced oil pressure, particularly when several bearings are worn.
Common warning signs include deep engine knocking, abnormal bearing wear, and low oil pressure. However, these symptoms can also result from other engine problems, so inspection and measurement are necessary to confirm the cause.
Excessive clearance can develop because of worn bearing surfaces, damaged crankshaft journals, incorrect bearing sizing, or previous machining work.
Replacing the bearings without checking the crankshaft can leave the underlying problem unresolved.
Related LS Engine Bearing Clearance Chart(for All LS Variants)
How to Measure Engine Bearing Clearance
Accurate measurement is essential before installing new bearings or completing an engine rebuild.
- Identify the engine. Find the engine code and obtain the correct service manual.
- Inspect the crankshaft. Check the journals for scoring, wear, taper, and out-of-round.
- Measure the journals. Use a calibrated outside micrometer to establish their actual diameters.
- Install the bearing shells. Clean the bearing housings and install the correct shells in the specified positions.
- Measure the assembled bearing bore. Use an appropriate bore gauge and follow the manufacturer’s procedure.
- Calculate the clearance. Subtract the crankshaft journal diameter from the assembled bearing inside diameter.
- Compare the result. Confirm that the measurement falls within the manufacturer’s specified limits.
The basic calculation is:
Bearing clearance = Assembled bearing inside diameter − Crankshaft journal diameter
For example, if the assembled bearing inside diameter is 2.0015 inches and the crankshaft journal measures 2.0000 inches, the diametral clearance is 0.0015 inch, or approximately 0.0381 mm.
This is an example of the calculation, not a specification for every engine.
Related How Tight Are Diesel Engine Valves(Correct Range)
Can You Use Plastigage to Check Bearing Clearance?
Yes. Plastigage is a practical tool for checking assembled bearing clearance during engine assembly.
A small strip is placed across a clean crankshaft journal. The bearing cap is then installed and tightened according to the manufacturer’s procedure. The crankshaft must not be rotated while the material is in place. After removing the cap, compare the flattened strip with the supplied scale to estimate the clearance.
Plastigage can help identify whether clearance is within an expected range, but it does not replace detailed dimensional measurements. Micrometers and bore gauges are especially useful for identifying journal taper, out-of-round, and other dimensional problems.
How to Maintain Correct Engine Bearing Clearance
Maintaining the correct clearance begins with accurate measurements and the correct replacement parts. Always use bearings specified for the engine and crankshaft dimensions. Some engines use different bearing grades or undersized bearings following crankshaft machining.
Keep bearing housings, crankshaft journals, and bearing surfaces clean during assembly. Follow the specified bearing-cap torque and tightening sequence, since incorrect assembly can affect measurements and component alignment.
Also, investigate the cause of any previous bearing failure. Low oil levels, blocked oil passages, oil pump problems, contamination, and overheating can damage new bearings if the underlying problem remains unresolved.
FAQs
What is the normal engine bearing clearance?
Some conventional automotive engines use main and connecting rod bearing clearances within a general range of approximately 0.0010–0.0030 inch. The correct range varies by engine design, so always verify the manufacturer’s specifications.
Should rod bearing clearance be tighter than main bearing clearance?
Not necessarily. The required clearance depends on the engine’s design, bearing dimensions, lubrication requirements, and intended operating conditions. Check the specifications for each bearing type separately.
Can excessive bearing clearance cause low oil pressure?
Yes. Excessive clearance can allow more oil to escape through bearing surfaces, contributing to low oil pressure. However, a worn oil pump, faulty pressure-relief valve, or other lubrication issue can cause similar symptoms.
Is bearing clearance the same as crankshaft endplay?
No. Bearing clearance is the diametral space between a bearing and its journal. Crankshaft endplay is the amount the crankshaft can move along its axis. They require different measurement procedures and specifications.
Can I fix excessive bearing clearance by using thicker oil?
Thicker oil may affect oil pressure, but it does not correct worn journals, damaged bearings, or incorrect bearing dimensions. Identify the cause and repair the engine according to its specifications.
Final words
An engine bearing clearance chart is a useful reference when diagnosing engine wear, replacing bearings, or rebuilding an engine. Main bearings, connecting rod bearings, camshaft bearings, and thrust bearings each have distinct functions and measurement requirements.
The most important step is to measure the components accurately and compare the results with the manufacturer’s specifications. Never rely on a general clearance chart alone when assembling an engine, because incorrect bearing clearance can lead to premature wear, oil pressure problems, and serious engine damage.
