This guide provides a comprehensive Yanmar oil filter cross-reference table, allowing you to match Yanmar OEM part numbers with equivalent filters from trusted aftermarket brands, such as Fleetguard, WIX, Fram, Baldwin, Donaldson, HIFI, Sakura, and others.
Yanmar Oil Filter Cross Reference
| Yanmar OEM Oil Filter | Common Engine Applications | Fleetguard | WIX | Fram | Baldwin | Donaldson | HIFI / Sakura / Other |
|---|---|---|---|---|---|---|---|
| 119005-35151 | Small Yanmar diesel engines (industrial, compact tractors) | LF3657 | 57040 | PH2808 | B1402 | P550162 | HIFI SO6117 / Sakura C-52080 |
| 119005-35160 | Compact engines, generators | LF3657 | 57040 | PH2808 | B1402 | P550162 | HIFI SO6117 |
| 119593-35400 | Marine & industrial engines | LF3827 | 51365 | PH3593A | B7039 | P550318 | HIFI SO6198 |
| 119593-35410 | Updated version of 35400 | LF3827 | 51365 | PH3593A | B7039 | P550318 | Sakura C-1104 |
| 129150-35153 | Yanmar TNV series | LF3754 | 57202 | PH7317 | B164 | P550388 | HIFI SO7034 |
| 127695-35150 | Larger diesel engines | LF3883 | 51515 | PH8A | B2 | P550008 | Sakura C-1906 |
| 127695-35151 | Heavy-duty applications | LF3883 | 51515 | PH8A | B2 | P550008 | HIFI SO1006 |
| 119305-35150 | Compact tractors | LF3657 | 57040 | PH2808 | B1402 | P550162 | Sakura C-52080 |
| 119305-35151 | Industrial & ag engines | LF3657 | 57040 | PH2808 | B1402 | P550162 | HIFI SO6117 |
| 128633-35400 | Marine diesel engines | LF3827 | 51365 | PH3593A | B7039 | P550318 | Sakura C-1104 |
| 119770-90620 | Engines with M24×1.5 thread | LF16015 | 57356 | PH3600 | B495 | P551807 | HIFI SO7126 |
| 124085-35100 | Older Yanmar tractor engines | LF3345 | 51452 | PH3614 | B164 | P550388 | Sakura C-1606 |
| 114250-35110 | Small industrial engines | LF3657 | 57040 | PH2808 | B1402 | P550162 | HIFI SO6117 |
| 15521-32450 | Compact diesel models | LF3345 | 51452 | PH3614 | B164 | P550388 | Sakura C-1606 |
| 194450-35100 | Marine & generator engines | LF3827 | 51365 | PH3593A | B7039 | P550318 | HIFI SO6198 |
Related Kubota Oil Filter Cross Reference(for All Brands)
How to Use a Yanmar Oil Filter Cross Reference
- Find your Yanmar OEM part number on the old oil filter or in the engine service manual.
- Locate the part number in the table and identify equivalent aftermarket brands.
- Confirm physical specifications, including:
- Thread size
- Gasket outside diameter
- Filter height
- Anti-drainback valve (if required)
- Purchase the filter that best matches both the OEM specification and your usage conditions.
Related Baldwin Filter Cross Reference(For All Brands)
Why Oil Filter Cross Referencing Matters for Yanmar Engines
Using cross-reference oil filters offers several advantages:
- Better availability in local markets
- Lower cost compared to OEM filters
- Access to premium filtration media from heavy-duty brands
- Reduced downtime for agricultural and marine equipment
As long as specifications match, aftermarket filters are safe and widely used in professional diesel maintenance.
Important Installation Tips
- Always lubricate the gasket with fresh engine oil before installation
- Hand-tighten according to manufacturer guidelines
- Replace the oil filter at every oil change interval
- Check for leaks after engine startup
Related Donaldson Filter Cross Reference(For All Brands)
FAQs
What is the cross reference for Yanmar 1GM10 oil filter?
For the Yanmar 1GM10 (a small marine diesel), the oil filter cross reference typically matches the Yanmar OEM number used on similar small industrial/marine engines. Common equivalent filters include:
- Fleetguard LF3657
- WIX 57040
- Fram PH2808
- HIFI SO6117 / Sakura C-52080
Always check the filter’s thread size and gasket diameter against your engine’s filter housing before purchase.
What oil to use in a Yanmar diesel engine?
Yanmar diesel engines generally require a high-quality diesel engine oil that meets the following:
- API Classification: CJ-4, CK-4, CI-4+, or higher (depending on engine age and use)
- Viscosity: For most Yanmar small/medium engines, 15W-40 is common; lighter viscosities (e.g., 10W-30) can be used in cooler climates if recommended by the engine manual
- Use marine-rated 4-stroke oil for marine applications
- Always follow the specific viscosity and spec recommendations in your engine’s owner or service manual
For the best results, prioritize oils that are:
- Designed for diesel engines
- Suitable for your operating temperature range
- From reputable brands with good additive protection
How do I know if an oil filter is compatible?
To confirm an oil filter is compatible with your Yanmar engine:
- Match the OEM part number with a known cross reference from a trusted table (like the one above).
- Check physical specifications:
- Thread size (e.g., M20x1.5, M24x1.5, etc.)
- Gasket outside/inside diameter
- Filter overall length
- Bypass/anti-drainback design (if required)
- Compare filtration media ratings (micron rating, efficiency)
- Consult your engine’s manual or parts seller if in doubt
- If the aftermarket filter matches these specs, it is considered acceptable
Never install a filter that doesn’t match the engine’s mechanical requirements—even if it “sort of fits.”
What is the part number for Yanmar 3GM30 oil filter?
The Yanmar 3GM30 (a popular 3-cylinder marine engine) typically uses the same oil filter cross references as other small/medium Yanmar diesels. Common OEM and equivalent part numbers include:
- Yanmar OEM: 119005-35151 / 119005-35160
- Fleetguard: LF3657
- WIX: 57040
- Fram: PH2808
- HIFI / Sakura: SO6117 / C-52080
Always verify with the engine’s manual or parts supplier before ordering.
What is the oil filter for Yanmar 1GM10?
The oil filter used on the Yanmar 1GM10 is the small spin-on type similar to other small Yanmar engines. Common listings include:
- Yanmar OEM: 119005-35151 or 119005-35160 (depending on production run)
- Equivalent aftermarket options include:
- Fleetguard LF3657
- WIX 57040
- Fram PH2808
- HIFI SO6117 / Sakura C-52080
Be sure to confirm the exact sheet metal configuration and thread before installation.
What oil for Yanmar 1GM10?
For the Yanmar 1GM10 diesel engine, the recommended oil type is:
- High-quality 4-stroke diesel engine oil
- Typical viscosity: 15W-40 for general marine and ambient temperature use
- In warmer climates, 20W-40 may be acceptable; in cool climates 10W-30 can be suitable (follow manual guidance)
- Use oil that meets or exceeds the appropriate API diesel service ratings (e.g., CJ-4, CK-4)
Because the 1GM10 often operates in marine environments, many technicians prefer oils with anti-corrosion and high detergency properties.
Final Thoughts
This Yanmar oil filter cross reference table provides a practical solution for finding compatible oil filters across multiple brands and engine types. Whether you maintain Yanmar tractors, marine engines, generators, or industrial equipment, cross referencing helps ensure proper lubrication, engine protection, and long service life.
