Toro oil filter 136-7848 is a commonly used spin-on filter found in many Toro lawn mowers, especially those powered by V-Twin engines. However, finding the exact OEM filter is not always convenient or cost-effective, which is why cross-referencing to compatible alternatives is essential.
Toro Oil Filter 136 7848 Cross Reference
| Brand | Part Number | Filter Type | Thread Size | Height (inches) | Notes |
|---|---|---|---|---|---|
| Toro (OEM) | 136-7848 | Spin-On | 3/4″-16 | 3.25 | Original Equipment |
| Briggs & Stratton | 492932S | Spin-On | 3/4″-16 | 3.40 | Common small engine use |
| Briggs & Stratton | 696854 | Spin-On | 3/4″-16 | 3.10 | OEM alternative |
| Kawasaki | 49065-7007 | Spin-On | 3/4″-16 | 3.40 | High-quality OEM option |
| Kawasaki | 49065-0721 | Spin-On | 3/4″-16 | 3.25 | Updated version |
| Kohler | 12 050 01-S | Spin-On | 3/4″-16 | 3.40 | Widely compatible |
| Kohler | 52 050 02-S | Spin-On | 3/4″-16 | 3.20 | Performance variant |
| Fram | PH3614 | Spin-On | 3/4″-16 | 3.40 | Popular aftermarket |
| Fram | PH8170 | Spin-On | 3/4″-16 | 3.00 | Shorter version |
| Wix | 51348 | Spin-On | 3/4″-16 | 3.40 | Premium filtration |
| Wix | 57035 | Spin-On | 3/4″-16 | 3.00 | Compact option |
| Napa Gold | 1348 | Spin-On | 3/4″-16 | 3.40 | Wix equivalent |
| Napa ProSelect | 21348 | Spin-On | 3/4″-16 | 3.40 | Budget alternative |
| Purolator | L10241 | Spin-On | 3/4″-16 | 3.40 | Reliable aftermarket |
| Purolator | PL10241 | Spin-On | 3/4″-16 | 3.40 | Synthetic media |
| Bosch | 3330 | Spin-On | 3/4″-16 | 3.40 | High efficiency filter |
| Mobil 1 | M1-102 | Spin-On | 3/4″-16 | 3.40 | Extended performance |
| STP | S3614 | Spin-On | 3/4″-16 | 3.40 | Affordable option |
| SuperTech | ST3614 | Spin-On | 3/4″-16 | 3.40 | Value brand |
| K&N | HP-1002 | Spin-On | 3/4″-16 | 3.40 | Performance filter |
| Baldwin | B33 | Spin-On | 3/4″-16 | 3.40 | Heavy-duty design |
| Hastings | LF113 | Spin-On | 3/4″-16 | 3.40 | Durable construction |
| Donaldson | P550162 | Spin-On | 3/4″-16 | 3.40 | Industrial-grade |
| Amsoil | EA15K12 | Spin-On | 3/4″-16 | 3.40 | Extended drain intervals |
| Champ | PH3614 Equivalent | Spin-On | 3/4″-16 | 3.40 | OEM supplier variant |
| Carquest | 85348 | Spin-On | 3/4″-16 | 3.40 | Wix cross reference |
| Carquest Red | 81348 | Spin-On | 3/4″-16 | 3.40 | Economy version |
| Fleetguard | LF3313 | Spin-On | 3/4″-16 | 3.40 | Heavy-duty engines |
| HifloFiltro | HF3614 | Spin-On | 3/4″-16 | 3.40 | Powersports compatibility |
| Mahle | OC575 | Spin-On | 3/4″-16 | 3.40 | European brand |
| Mann-Filter | W 75/3 | Spin-On | 3/4″-16 | 3.40 | High-quality filtration |
| Ryco | Z386 | Spin-On | 3/4″-16 | 3.40 | Australian market |
| Sakura | C-1139 | Spin-On | 3/4″-16 | 3.40 | Durable aftermarket |
| Sure Filter | SFO3614 | Spin-On | 3/4″-16 | 3.40 | General-purpose use |
| Luber-finer | PH3614 | Spin-On | 3/4″-16 | 3.40 | Commercial applications |
| AC Delco | PF53 | Spin-On | 3/4″-16 | 3.40 | Automotive crossover use |
| Motorcraft | FL-910S | Spin-On | 3/4″-16 | 3.40 | Compact compatible filter |
| Pennzoil | PZ-36 | Spin-On | 3/4″-16 | 3.40 | Aftermarket option |
| Quaker State | QS3614 | Spin-On | 3/4″-16 | 3.40 | Budget-friendly |
| MicroGard | MGL3614 | Spin-On | 3/4″-16 | 3.40 | Parts store brand |
Related Toro 24.5 HP Engine Oil Filter Cross Reference(For All Brands)
Key Considerations When Choosing a Replacement
When selecting a cross-referenced oil filter, there are several important factors to keep in mind to ensure proper fit and optimal engine performance.
Thread compatibility is critical, and the replacement filter must match the 3/4″-16 thread size exactly. Using the wrong thread size can lead to improper installation or damage to the engine.
Gasket fit is equally important. The gasket should align perfectly with the mounting surface to prevent oil leaks and maintain proper sealing during operation.
Filter height should also be considered. Make sure there is enough clearance in the engine compartment to accommodate the filter, especially if you are choosing a longer or shorter variant.
Filtration quality plays a major role in engine protection. It is always recommended to choose trusted and reputable brands that offer reliable filtration performance.
Finally, valve features such as anti-drainback and bypass valves are essential. These components help maintain oil pressure and ensure proper lubrication, especially during startup and under demanding conditions.
Related Honda Engine Oil Filter(Top 5 Best Picks 2026)
Toro 136-7848 Oil Filter Specifications
| Specification | Value |
|---|---|
| Filter Type | Spin-On Oil Filter |
| Thread Size | 3/4″-16 |
| Gasket Outer Diameter | ~2.8–3.0 inches |
| Height | ~3.0–3.4 inches |
| Anti-Drainback Valve | Yes |
| Bypass Valve | Yes |
| Application | Lawn Mowers, Small Engines |
Related PF64 Oil Filter Cross Reference(for All Brands)
Final words
The Toro 136-7848 oil filter is widely supported across numerous brands, making it easy to find a suitable replacement without compromising engine performance. By matching critical specifications such as thread size, gasket diameter, and filter height, you can confidently choose from a broad range of high-quality alternatives.
This comprehensive cross-reference table ensures you always have the right filter option available, whether you’re performing routine maintenance or replacing a worn-out filter. Always prioritize quality and compatibility to keep your lawn mower or small engine running smoothly for years to come.
