One key factor in maintaining their reliability is using the correct engine oil and ensuring proper oil capacity.
This guide details the oil capacities of the most popular 22 HP Kawasaki engines and provides a clear table to help you find the right oil volume for your specific model.
22 HP Kawasaki Engine Oil Capacity
| Engine Series | Model | Displacement (cc) | Oil Capacity (No Filter) | Oil Capacity (With Filter) |
|---|---|---|---|---|
| FR Series | FR651V | 726 cc | 1.8 qt / 1.7 L | 2.1 qt / 2.0 L |
| FR Series | FR691V | 726 cc | 1.9 qt / 1.8 L | 2.1 qt / 2.0 L |
| FR Series | FR730V | 726 cc | 2.0 qt / 1.9 L | 2.3 qt / 2.2 L |
| FS Series | FS651V | 726 cc | 1.8 qt / 1.7 L | 2.1 qt / 2.0 L |
| FS Series | FS691V | 726 cc | 1.9 qt / 1.8 L | 2.1 qt / 2.0 L |
| FS Series | FS730V | 726 cc | 2.0 qt / 1.9 L | 2.2 qt / 2.1 L |
| FS Series | FS651V-AS00 | 726 cc | 1.8 qt / 1.7 L | 2.1 qt / 2.0 L |
| FS Series | FS730V-AS04 | 726 cc | 2.0 qt / 1.9 L | 2.2 qt / 2.1 L |
| FX Series | FX651V | 726 cc | 1.9 qt / 1.8 L | 2.2 qt / 2.1 L |
| FX Series | FX691V | 726 cc | 1.9 qt / 1.8 L | 2.2 qt / 2.1 L |
| FX Series | FX691V-S00 | 726 cc | 1.9 qt / 1.8 L | 2.2 qt / 2.1 L |
| FX Series | FX730V | 726 cc | 2.0 qt / 1.9 L | 2.3 qt / 2.2 L |
| FT Series | FT691V EFI | 726 cc | 1.9 qt / 1.8 L | 2.2 qt / 2.1 L |
Related 23 HP Kawasaki Engine Oil Type(Detailed Guide)
Why Engine Oil Capacity Matters
Using too much or too little oil in your Kawasaki engine can lead to:
- Overheating – Insufficient oil means less lubrication and more friction.
- Engine Wear – Excess or low oil can cause premature damage to engine components.
- Oil Foaming – Overfilling leads to aeration of oil, reducing its lubricating ability.
- Void Warranty – Incorrect oil use may void your equipment’s warranty.
That’s why it’s critical to know the exact oil capacity of your 22 HP Kawasaki engine and change it at the manufacturer-recommended intervals (typically every 100 hours or once per season).
Kawasaki Recommended Oil Type
Kawasaki recommends SAE 10W-30 or SAE 10W-40 for most of their small engines, especially in warmer climates. In colder conditions, SAE 5W-20 or 5W-30 may be acceptable. Use API SJ or higher certified oil.
Related 4 Cycle Engine Oil(Top 5 Best Oil 2025)
How to Change Oil in a 22 HP Kawasaki Engine
Changing your oil at regular intervals ensures the engine runs cooler and lasts longer. Here’s a quick step-by-step process:
- Warm Up the Engine: Run it for 5 minutes to thin the oil.
- Drain the Oil:
- Locate the drain plug (usually at the base of the crankcase).
- Place an oil pan underneath and remove the plug.
- Allow the oil to drain fully.
- Replace Oil Filter (If Applicable):
- Use a filter wrench to remove the old filter.
- Lightly oil the gasket of the new filter and hand-tighten it.
- Refill with Fresh Oil:
- Use a funnel to refill oil based on your model’s capacity.
- Check the dipstick and add gradually to avoid overfilling.
- Run the Engine: Let it idle for 1-2 minutes, then shut off and recheck the level.
Related Universal 2 Cycle Engine Oil(Top 3 Best 2025)
Common Mistakes to Avoid
- Overfilling Oil: Too much oil can cause foaming and internal damage.
- Using the Wrong Grade: Always match oil viscosity to your climate and manual.
- Skipping Oil Filter Changes: This traps contaminants and reduces oil life.
- Neglecting Regular Changes: Dirty oil thickens and leads to poor lubrication.
FAQs
How much oil does a 22 horsepower engine hold?
A typical 22 horsepower Kawasaki engine holds between 1.8 and 2.1 quarts (1.7 and 2.0 liters) of oil without a filter, and up to 2.3 quarts (2.2 liters) with a filter installed. Always refer to your engine model’s manual for exact specifications.
Related 19 HP Kawasaki Engine Oil Capacity(+ Top 3 Best Oils)
How much oil does a Kawasaki FR651V 22.0 take?
The Kawasaki FR651V 22 HP engine takes approximately 1.8 quarts (1.7 liters) without an oil filter, and 2.1 quarts (2.0 liters) with a filter.
How much oil does a 21 hp Kawasaki engine hold?
Most 21 HP Kawasaki engines like the FR600V or similar hold around 1.8 to 2.0 quarts (1.7 to 1.9 liters), depending on whether the oil filter is changed during the oil service.
How much oil does a 23 hp Kawasaki engine hold?
A 23 HP Kawasaki engine, such as the FR691V or FX691V, typically holds about 1.9 quarts (1.8 liters) without the filter, and up to 2.2 quarts (2.1 liters) with a filter.
How many cc is a 22 hp engine?
A 22 HP Kawasaki engine generally has a displacement of 726 cc, which is standard across models like the FR651V, FS651V, FX651V, and FT691V.
Related Kawasaki 23 HP Engine Oil Filter(Top 5 BEST 2025)
How much oil does a 27 hp Kawasaki motor take?
The 27 HP Kawasaki FX850V engine holds approximately 2.1 quarts (2.0 liters) without the filter and up to 2.4 quarts (2.3 liters) with a filter.
How much oil does a 19 horsepower Kawasaki engine take?
A 19 HP Kawasaki engine like the FR600V usually takes 1.6 to 1.8 quarts (1.5 to 1.7 liters) of oil, depending on whether or not the oil filter is being changed during service.
Final Thoughts
Maintaining proper oil levels in your 22 HP Kawasaki engine is vital to performance and longevity. Whether you’re running an FR, FS, FX, or FT series model, knowing the correct oil capacity, using the right grade, and following a consistent maintenance schedule will keep your mower or equipment running like new for years to come.
Use the table above as your quick reference whenever it’s time for an oil change, and don’t forget to mark your maintenance schedule to stay ahead of wear and tear.
