This guide provides a complete Hino truck oil capacity table, covering light-duty, medium-duty, and heavy-duty models, along with practical oil-change tips to help you service your Hino truck correctly.
Hino Truck Engine Oil Capacity
Hino 300 Series (Dutro / Light-Duty)
| Hino Model | Engine Code | Engine Size | Oil Capacity |
|---|---|---|---|
| Hino 300 414 | N04C-TV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 300 514 | N04C-UV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 300 616 | N04C-TV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 300 716 | N04C-UV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 300 816 | N04C-WV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 300 917 | N04C-WU | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 300 921 | N04C-WV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 300 924 | N04C-WU | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino Dutro X | N04C | 4.0L Diesel | 9.0–9.5 L |
| Hino 300 Hybrid | N04C Hybrid | 4.0L Diesel | 9.0 L (9.5 qt) |
Hino 500 Series (Ranger / Medium-Duty)
| Hino Model | Engine Code | Engine Size | Oil Capacity |
|---|---|---|---|
| Hino 500 FA | J05E-TF | 5.1L Diesel | 12.0 L (12.7 qt) |
| Hino 500 FB | J05E-TB | 5.1L Diesel | 12.0 L (12.7 qt) |
| Hino 500 FC | J05E-TE | 5.1L Diesel | 12.0 L (12.7 qt) |
| Hino 500 FD | J05E-TB | 5.1L Diesel | 12.0 L (12.7 qt) |
| Hino 500 FE | J08E-VK | 7.7L Diesel | 15.0 L (15.9 qt) |
| Hino 500 FG | J08E-WD | 7.7L Diesel | 15.0 L (15.9 qt) |
| Hino 500 FL | J08E-VA | 7.7L Diesel | 15.5 L (16.4 qt) |
| Hino 500 FM | J08E | 7.7L Diesel | 15.0–16.0 L |
| Hino 500 GT | J08E | 7.7L Diesel | 15.0–16.0 L |
| Hino Ranger Pro | J08E / J07E | 6.4–7.7L Diesel | 14–16 L |
Related Semi Truck Differential Oil Capacity Chart(For All Models)
Hino 600 Series (North America)
| Hino Model | Engine Code | Engine Size | Oil Capacity |
|---|---|---|---|
| Hino 155 | N04C-TV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 165 | N04C-TV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 185 | N04C-WV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 195 | N04C-WV | 4.0L Diesel | 9.5 L (10.0 qt) |
| Hino 238 | J05E-TP | 5.1L Diesel | 12.0 L (12.7 qt) |
| Hino 258 | J05E-TP | 5.1L Diesel | 12.0 L (12.7 qt) |
| Hino 268 | J08E-VC | 7.7L Diesel | 15.0 L (15.9 qt) |
| Hino 268A | J08E-VC | 7.7L Diesel | 15.0 L (15.9 qt) |
| Hino 338 | J08E-VC | 7.7L Diesel | 15.0 L (15.9 qt) |
| Hino XL7 | A09C | 8.9L Diesel | 28.0 L (29.6 qt) |
| Hino XL8 | E13C | 12.9L Diesel | 33.0 L (34.9 qt) |
Hino 700 Series (Profia / Heavy-Duty)
| Hino Model | Engine Code | Engine Size | Oil Capacity |
|---|---|---|---|
| Hino 700 SH | E13C | 12.9L Diesel | 33.0 L (34.9 qt) |
| Hino 700 SS | E13C | 12.9L Diesel | 33.0 L (34.9 qt) |
| Hino 700 FS | E13C | 12.9L Diesel | 33.0 L (34.9 qt) |
| Hino 700 FR | E13C | 12.9L Diesel | 33.0 L (34.9 qt) |
| Hino 700 Profia | E13C | 12.9L Diesel | 33.0 L (34.9 qt) |
| Hino 700 Tractor Head | A09C | 8.9L Diesel | 28.0 L (29.6 qt) |
| Hino 700 Dump | K13C | 12.9L Diesel | 32–34 L |
Related Cross Reference Chart for Oil Filters(For ALL Brands)
Common Standalone Hino Engines (Global)
| Engine Code | Displacement | Typical Application | Oil Capacity |
|---|---|---|---|
| N04C | 4.0L | Hino 300 / 600 | 9.0–9.5 L |
| J05E | 5.1L | Hino 500 / 600 | 12.0 L |
| J07E | 6.4L | Hino Ranger | 14.0 L |
| J08E | 7.7L | Hino 500 / 600 | 15–16 L |
| A09C | 8.9L | Hino XL7 / 700 | 28.0 L |
| E13C | 12.9L | Hino 700 / XL8 | 33.0 L |
| K13C | 12.9L | Heavy-duty Hino | 32–34 L |
| P11C | 10.5L | Older Hino Trucks | 29.0 L |
Best Engine Oils for Hino Trucks
Click the Links Below to Check The Latest Prices on AMAZON
1. Shell Rotella T6 Full Synthetic 15W-40
Key Features:
- Full synthetic formulation designed for heavy-duty diesel engines
- Excellent protection under high temperatures and heavy load conditions
- Helps reduce engine wear, deposits, and oil breakdown
- Maintains viscosity stability for extended oil drain intervals
- Meets modern diesel engine performance standards, including CK-4 and CJ-4
Best For: Long-haul driving, high-load operations, and severe working conditions.
2. Valvoline Heavy Duty Full Synthetic 15W-40 Diesel Engine Oil
Key Features:
- Full synthetic oil engineered for commercial diesel engines
- Provides strong wear protection for valve trains and turbocharged engines
- Helps control sludge and soot buildup in modern diesel systems
- Performs reliably in both hot and cold operating environments
- Suitable for on-highway trucks, fleets, and construction equipment
Best For: Medium- and heavy-duty Hino trucks requiring consistent performance and durability.
3. Chevron Delo 400 XLE Synthetic Blend 15W-40
Key Features:
- Synthetic blend oil formulated for heavy-duty diesel applications
- Strong resistance to oxidation and thermal breakdown
- Designed to handle high soot levels common in diesel engines
- Helps maintain engine cleanliness and reduce component wear
- Compatible with emission-controlled diesel engines
Best For: Fleet use and cost-effective maintenance without sacrificing protection.
Related Diesel Truck Transmission Fluid(Top 5 Best Picks)
Recommended Engine Oil Type for Hino Trucks
Most modern Hino diesel engines recommend:
- SAE 10W-30 or 15W-40
- API CJ-4, CK-4, or newer
- Low-ash oil for emissions-controlled engines (DPF-equipped)
For newer models with DPF and SCR systems, CK-4 10W-30 is commonly recommended for improved fuel economy and engine protection.
Oil Change Tips for Hino Trucks
- Always change the oil filter during oil changes
- Warm the engine slightly before draining oil
- Allow sufficient drain time to remove old oil completely
- Recheck the oil level after running the engine for a few minutes
- Never exceed the maximum oil level mark
Regular oil changes help prevent turbocharger wear, injector problems, and excessive soot buildup.
Related Oshkosh Truck Engine Oil Capacity Chart(For ALL Models)
How Often Should You Change Oil in a Hino Truck?
Typical oil change intervals depend on usage:
- Light-duty trucks: Every 10,000–15,000 km
- Medium-duty trucks: Every 15,000–25,000 km
- Heavy-duty trucks: Every 25,000–40,000 km
Severe operating conditions such as heavy loads, frequent idling, dusty environments, or stop-and-go driving may require shorter intervals.
FAQs
How much oil does a Hino take?
The engine oil capacity for Hino trucks varies by model and engine size. Light-duty Hino 300 Series trucks typically require 9–10 liters, medium-duty 500 Series trucks need 12–16 liters, and heavy-duty 700 Series trucks can hold 28–34 liters. Always include the oil filter when calculating total capacity.
How much oil does a 3.0 L diesel take?
A 3.0 L diesel engine, commonly found in light-duty trucks or Hino 300 variants, typically requires approximately 7–8 liters (7.4–8.5 quarts) of engine oil, along with a filter change. Exact capacity may vary slightly depending on engine variant.
Related Dump Truck Hydraulic Fluid(Top 5 Best Picks)
How much oil does a 2006 Hino 268 take?
The 2006 Hino 268, equipped with a J08E-VC 7.7L diesel engine, has an oil capacity of approximately 15 liters (15.9 quarts), including the oil filter replacement.
What is the capacity of Hino 300 truck?
Hino 300 Series trucks generally have a 4.0L diesel engine. Their oil capacity ranges from 9 to 9.5 liters (9.5–10 quarts), including the oil filter. This applies to most models like 616, 716, 816, and hybrid variants.
How many gallons of oil does a D13 hold?
The Hino D13 engine, typically found in heavy-duty 700 Series trucks, has a capacity of 33 liters, which is roughly equivalent to 8.7 gallons of engine oil with filter replacement.
How much oil does a 3.0 L engine hold?
A 3.0 L diesel engine usually requires 7–8 liters (7.4–8.5 quarts) of oil, depending on the exact engine type and whether the oil filter is changed during service.
Final Thoughts
Understanding the correct Hino truck engine oil capacity is essential for maintaining reliability, efficiency, and engine longevity. From the compact Hino 300 Series to the powerful Hino 700 heavy-duty trucks, each model has specific lubrication requirements that should never be ignored.
Using the correct oil type and quantity not only protects your engine but also reduces downtime and long-term maintenance costs. Always confirm your exact engine code before servicing, especially for imported or older Hino models.
